80mm Hydraulic Cylinder 56-1500mm Stroke High-Temperature Resistant

Name: 80mm Hydraulic Cylinder 561500mm Stroke HighTemperature Resistant
Brand: Guoyue
Price: 1 USD

China 80mm Hydraulic Cylinder 56-1500mm Stroke High-Temperature Resistant wholesale

Brand Name : Guoyue

Place of Origin : Jiangsu, China

MOQ : 1 piece

Price : USD1,000-10000/pieces

Certification : iso

Model Number : customized

Packaging Details : Standard Export Package

Delivery Time : 12~60 days depends on products type

Payment Terms : T/T

Supply Ability : 2500 Ton/Tons Per Year

Product name : Hydraulic Cylinder

Pressure : 1MPa

Power : 16MPa

Dimension(L*W*H) : 1775*195*195mm

Rod Diameter : 56mm

Maximum Stroke : 1500mm

Outer Tube Diameter : 102mm

Inner Tube Diameter : 80mm

Material : Customized

Usage : Machinery

Contact Now

Oem Buffer 80 56-1500 Buffered and High-temperature Resistant Hydraulic Cylinder Construction Machinery Cylinders

Good Hydraulic Cylinders – We Make Sure They Work Inside Parts
The tube follows GUOYUE CD250 style.
Tube steel can be 45#, 42CrMo, or 27SiMn.
Hole is ground to H8 and feels smooth, Ra under 0.4 μm.
Head, base, ears, and piston are only 45# steel.
We do not use cast iron or cast steel. Slow-Down Parts
You can pick fixed bumpers or floating bumpers so the rod slows down safe at any speed or load. Welds
We hit every heavy-load weld with ultrasound.
This takes away most of the stress and makes the weld last longer. Seals
We only use top seals from NOK (Japan), Trelleborg (Sweden), Merkel and GP (Germany).
We do not use local seals. Checks
Each cylinder is tested to GB/T15622-2005 and our own Q/GAKY014-2023.
You get a test sheet and a pass paper. Promise
We give one year cover from ship date.
If it breaks because of how we made it, we fix or swap it for free. Advantages:
This cylinder is strong. It uses thick steel and hard chrome. It does not bend. The seal is good, so oil stays in. It works when it is very hot. It lifts 2500 mm and pushes hard. The rod moves smooth and stops soft. It lasts long and needs little fix. It is light and fits small space. The ports fit most hoses. The paint stops rust. It runs all day with no leak. It starts fast and saves power. It holds load when power is off. The price is low for the work it gives. It is quiet. It is safe. It meets world rules. It ships fast. It fits quick with no extra tools. It works in dust, rain, and sun. It lifts and drops slow or fast as you need. It keeps oil clean, so parts wear less. It is ready for hard jobs. It is good for farms, roads, and big sites. It is built to work and not break. Where It Works:
Use it in diggers, loaders, dump trucks, farm lifts, shop presses, and home lifts. It lifts rock, sand, hay, and boxes. It pushes snow blades and scrap metal. It helps fix cars and move bins.

Application	Engineering machinery, mine, shipping, metallurgy, water conservancy, offshore, agriculture, etc.
Seal	Parker, Merkel, NOK, Hallite,etc.
Paint	Red, Grey, Yellow, Black, etc.
Material	St52, CK45, 4140, Duplex2205, Stainless Steel 304/316, etc.
Certificate	ABS, Lloyds, SGS, etc.
Package	Bubble-wrap packing, then in wooden case.
Color	choose the color according to customer requirement
Core components	Bearing,Pressure vessel,Pump
Is it a standard part?	Nonstandard
Structure	Piston Type, Plunger Type, Telescopic Type,
Power	Hydraulic & Pneumatic
Brand	Guoyue
Sample	Available

80mm Hydraulic Cylinder 56-1500mm Stroke High-Temperature Resistant

1. who are we?
We are based in Jiangsu, China, start from 2022,sell to Domestic Market(40.00%),Africa(10.00%),North America(10.00%),South
America(8.00%),Southeast Asia(6.00%),Western Europe(5.00%),Eastern Europe(5.00%),Mid East(5.00%),Central America(5.00%),Eastern
Asia(2.00%),Oceania(2.00%),Northern Europe(1.00%),South Asia(1.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
hydraulic cylinder,hydraulic cylinder,Single-acting hydraulic cylinder,Double-acting hydraulic cylinder,construction machinery
hydraulic cylinder

4. why should you buy from us not from other suppliers?
Guoyue Hydraulic Equipment Manufacturing (Jiangsu) Co., Ltd., with a registered capital of 50 million yuan, is a private
technology enterprise that integrates research, design, development, production, operation, and service. The company specializes
in the

5. what services can we provide?
Accepted Delivery Terms: FOB；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T;
Language Spoken:English,Chinese
